V1200 / CPE / AC1200 Dual-Band Wi-Fi VDSL Modem Router

IEEE 802.3、IEEE 802.3u、IEEE 802.3ab

ITU G.993.2, Up to 17a 、ITU-T G.993.5 (G.vector)、ITU-T G.998.4 (G.INP)

3 10/100 RJ45 LAN Ports
1 10/100/1000 RJ45 LAN/WAN Port
1 RJ11 Port
1 USB 2.0 Port

WPS Button
Wireless On/Off Button
Power On/Off Button
Reset Button

12V 1.5A

Power、Internett、USB、WPS、WLAN 2.4G、WLAN 5G、LAN(1-4）

IEEE 802.11a/n/ac 5GHz
IEEE 802.11b/g/n 2.4GHz

867Mbps at 5GHz
300Mbps at 2.4GHz

2.4GHz <20dBm(EIRP)
5GHz <23dBm(EIRP)

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryptions, Wireless MAC Filtering

Supports IPv4 and IPv6

ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MERIPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs

ATM QoS, Bandwidth Control

Web Based Con guration(HTTP), Remote management,
command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware
Upgrade, Diagnostic Tools

Parental Control, Network Address Translation(NAT),
Port Mapping(Grouping), Static Routing, RIP v1/v2(optional), DNS Relay,
DDNS, IGMP V1/V2/V3

Server, Client, DHCP Client List, Address Reservation, DHCP Relay

Support Samba(Storage)/FTP Server

CE、RoHS

AC1200 Dual-Band Wireless VDSL2 Modem Router V1200*1
External Splitter*1
RJ11 DSL Cable*1
RJ45 Ethernet Cable*1
Power Adapter*1
Quick Installation Guide*1

Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
